New MAHR MARCHECK PLUS | Measuring Machines

Description

The MarCheck plus control electronic is designed exclusively for the operation of MarShaft MAN units (sizes 400 mm to 2400 mm) with the MarWin EasyShaft MAN measurement and evaluation software. The control electronic is available in the basic version (4 channels) or premium version (9 channels). The Premium version has two additional connections for temperature sensors required for the optional temperature compensation.
With the new evaluation software MarWin EasyShaft MAN, Mahr again sets new standards in manual shaft measurement technology on the market.
The software operation concept was largely taken over by the very successful evaluation software of the optical Mahr shaft measuring devices of the MarShaft SCOPE plus product line.
The very simple, intuitive operation minimizes the training requirements. The evaluation software MarWin EasyShaft MAN can be mastered in a very short time. No programming knowledge is required; the creation of measuring programs is done in Teach-In mode. The individual characteristics are simply measured one after the other and subsequently this measurement sequence is stored as a measurement program.
A robust panel PC with 15.6" touchscreen monitor (including stand) is suitable for use in production.
